Winco Benchmark 54016 Countertop Oven
Winco Benchmark 54016 Multi-Function Countertop Oven (27" Wide, 16" Opening, 1750W, 120V, Salamander/Baker/Oven)
The Winco Benchmark 54016 is a 27-inch wide countertop multi-function oven that operates as a salamander, a baker, or a finishing oven from a single 120V plug. The 16-by-3-inch opening accepts a 16-inch pizza, a full-size sheet pan rotated long-side-in, or multiple longer sub sandwiches. The 90 to 550 degree Fahrenheit thermostat range covers proofing through high-temperature salamander work.
Stainless steel construction, full insulation that keeps the exterior under 150 degrees Fahrenheit, separate top and bottom heater switches, a 60-minute timer with stay-on, and 3-inch adjustable legs for easy under-unit cleaning. The 54016 is the wider sibling of the 54012, designed for operations that need 16-inch pizza capacity or longer sandwich runs without moving to a full-size deck oven.
Best Use Cases
- Pizza shop 16-inch personal and pickup oven
- Sub shop and sandwich franchise melt station
- Convenience store hot food program
- Bar food and snack service with longer sub menu
- Concession stand at sports venues
- Country club halfway house or pool deck
- Bakery roll and pastry finishing
- Cafeteria or hospital floor pantry
- Hotel guest-floor breakfast station
- Catering commissary backup or auxiliary oven
Three Functions In One Cabinet
Operator-selectable top, bottom, or both elements turns the 54016 into three appliances. Top only for salamander work and cheese melting. Bottom only for pizza, focaccia, and bread baking. Both elements for full oven mode on subs, casseroles, hot apps, and proteins. The 60-minute timer with stay-on covers both timed and indefinite-hold operations.
Fully Insulated Stainless Steel Cabinet
Heavy insulation keeps exterior cabinet temperature under 150 degrees Fahrenheit during sustained high-heat use. Stainless steel inside and out cleans with a damp cloth and degreaser. The 3-inch adjustable legs lift the unit for easy floor and undercabinet cleaning.
16-Inch Opening Advantage
The 16-by-3-inch opening is the key upgrade over the 54012. It accepts a 16-inch round pizza, a full-size sheet pan rotated long side in, or a longer sub. Operations running a 16-inch pizza on the menu cannot use the 54012. The 54016 is the smallest countertop multi-function oven that handles that size pie.
Temperature Range
90 to 550 degrees Fahrenheit covers proofing, holding, baking, and salamander work. The thermostat is continuous-variable for precise control on every menu item.
Comparison to the 54012
The 54012 is the same oven in a narrower 23-inch cabinet with a 12-by-3-inch opening. Choose the 54012 if your menu is 12-inch pizzas and half-size pan capacity. Choose the 54016 for 16-inch pies and longer pan runs.
Comparison to a Dedicated Pizza Oven
A dedicated countertop pizza oven like the Winco EPO-1 cooks pizza and only pizza. The 54016 cooks pizza plus subs, melts, finishing, and broiling. Choose the EPO-1 if your only menu item is pizza. Choose the 54016 for menu flexibility from a single appliance.
Specifications
| Model Number | 54016 |
| Manufacturer | Winco |
| Series | Benchmark |
| Type | Multi-function countertop oven (salamander, baker, oven) |
| Exterior Dimensions | 27"W x 17"D x 10"H (legs add 3") |
| Opening | 16" x 3" |
| Capacity | Fits 16-inch pizza |
| Temperature Range | 90 to 550 degrees Fahrenheit |
| Heater Control | Independent top and bottom switches |
| Timer | 60-minute with stay-on |
| Power | 1750 watts |
| Voltage | 120V, 60Hz, 1-phase |
| Amperage | 14.6 amps |
| Plug | NEMA 5-15P (US), NEMA 5-20P (Canada) |
| Construction | Stainless steel, fully insulated |
| Max Exterior Temperature | Under 150 degrees Fahrenheit |
| Legs | 3-inch adjustable |
| Certifications | cETLus, ETL-Sanitation |
Installation Requirements
The 54016 plugs into a standard 120V 15-amp circuit using a NEMA 5-15 receptacle in the United States. In Canada it ships with a NEMA 5-20 plug requiring a 20-amp receptacle. At 14.6 amps the unit should run on a dedicated circuit.
Installation Checklist
- Dedicated 120V 15-amp circuit (US) or 20-amp circuit (Canada)
- NEMA 5-15 receptacle (US) within reach of factory cord
- Heat-resistant countertop rated for unit weight
- 3-inch leg clearance under the unit
- Combustible surface clearance per manual
- Hood requirements confirmed with local AHJ
- Initial burn-in cycle per manual before first food contact
Frequently Asked Questions
What can the 54016 cook?
The 54016 functions as a salamander, baker, and full oven. It bakes up to 16-inch pizzas, toasts longer sub sandwiches, melts cheese, finishes casseroles, broils thin proteins, holds product, and reheats hot apps.
Does it have separate top and bottom controls?
Yes. Independent switches control top and bottom heating elements for salamander, bake, or full oven operation.
How hot does the outside cabinet get?
Under 150 degrees Fahrenheit on the exterior even during sustained high-heat use.
What size pizza fits?
A 16-inch pizza fits the 16-by-3-inch opening. For smaller 12-inch pizzas use the 54012 in a more compact cabinet.
Is the 54016 a convection oven?
No. Radiant heat with separate top and bottom elements. No forced air convection.
Does the 54016 need a hood?
Hood requirements depend on local code and menu. Many jurisdictions allow ventless or Type II operation for countertop electric ovens. Confirm with your AHJ.
What is the warranty?
Winco provides a manufacturer warranty on the Benchmark series. Refer to the spec sheet for current terms.
