Atosa MBF8504GR 82-Inch Three Door Commercial Reach-In Freezer, Bottom Mount, 68 cu. ft.
Atosa MBF8504GR 82-Inch Three Door Commercial Reach-In Freezer, Bottom Mount, 68 cu. ft.
The Atosa MBF8504GR is a three door commercial reach-in freezer with a bottom mount compressor. It holds 68 cu. ft. at -8°F to 0°F.
It is the largest bottom mount model in the line: three doors, nine shelves and 68 cu. ft. Note that it needs a 208-230V circuit with an L14-20R outlet, not a standard wall plug.
Need a different size? Shop all commercial freezers or compare reach-in freezers.
Most units ship within one business day from our warehouse with free freight to the lower 48.
Where the MBF8504GR Fits Best
- Cook lines: frozen product close to where you cook
- Restaurant kitchens: frozen proteins, fries and prepared foods
- Catering and banquets: frozen stock for event prep
- Pizza and bakery: dough, crusts and desserts
Why Kitchens Choose the MBF8504GR
- 68 cu. ft. in an 81-9/10" wide cabinet
- Holds -8°F to 0°F for meat, seafood, fries, desserts and prepared foods
- Three locking solid doors
- 9 adjustable shelves and LED interior lighting
- 3-year parts and labor and 5-year compressor warranty
Cooling and Controls
A 1 HP compressor runs on R290, a natural refrigerant. A digital controller holds -8°F to 0°F, and down duct airflow spreads cold air evenly from top to bottom. Automatic evaporation takes care of condensate water for you. It is a self-contained, plug-in unit, so there is nothing to plumb.
Built for Daily Commercial Use
The inside and outside are stainless steel, and the back is galvanized steel. The doors close on their own and stay open when you swing them all the way, which makes loading easier. They open to 105°. Every door locks, the handles are recessed, and magnetic gaskets seal tight. It rolls on pre-installed 4" casters, so you can pull it out to clean behind it.
Why Bottom Mount?
On this freezer the compressor sits under the cabinet, where it is easy to reach for cleaning and service. Prefer the compressor up top, away from floor dust and grease? See our top mount freezers.
The Atosa Bottom Mount Freezer Line
Every model below is a bottom mount reach-in that holds -8°F to 0°F:
| Model | Doors | Width | Height | Capacity | Note |
|---|---|---|---|---|---|
| MBF8520GR | 1 | 24-1/4" | 63-1/4" | 8.3 cu. ft. | Low height, 2" casters |
| MBF8531GR | 1 | 25-5/8" | 76-3/8" | 12.57 cu. ft. | Low height, right hinge |
| MBF8501GR | 1 | 27" | 83-1/10" | 19.1 cu. ft. | Right hinge |
| MBF8501GRL | 1 | 27" | 83-1/10" | 19.1 cu. ft. | Left hinge |
| MBF8502GR | 2 | 39-1/2" | 83-1/10" | 28.5 cu. ft. | ENERGY STAR® |
| MBF8503GR | 2 | 54-2/5" | 83-1/10" | 43.8 cu. ft. | ENERGY STAR® |
| MBF8504GR (this model) | 3 | 81-9/10" | 83-1/10" | 68 cu. ft. | 115/208-230V, L14-20P plug |
Need the same size cabinet for refrigerated food? See the matching Atosa MBF8508GR three door refrigerator.
Specifications
| Spec | Detail |
|---|---|
| Configuration | Commercial reach-in freezer, three-section, bottom mount |
| Doors | (3) locking solid doors, self-closing with stay-open feature |
| Capacity | 68 cu. ft. |
| Shelves | (9) adjustable shelves, 3 per section |
| Exterior dimensions | 81-9/10" W x 31-7/10" D x 83-1/10" H |
| Temperature range | -8°F to 0°F |
| Temperature control | Digital |
| Refrigerant | R290 hydrocarbon |
| Compressor | 1 HP |
| Condensate | Automatic evaporation |
| Lighting | Interior LED |
| Construction | Stainless steel interior and exterior, galvanized steel back |
| Casters | 4", pre-installed |
| Electrical | 115/208-230V / 60Hz / 1-phase, 6.2 amps |
| Plug | NEMA L14-20P |
| Net weight | 551 lb |
| Shipping weight | 628 lb |
| Extra shelf | W0402387 (left and right sections) and W0402388 (middle section) (each includes 4 shelf clips) |
| Warranty | 3-year parts and labor, 5-year compressor |
| Certifications | cETLus, ETL-Sanitation |
Installation and Care
Set the freezer on a level floor near a 208-230V circuit with a NEMA L14-20R outlet. Have an electrician check it before delivery. Leave the unit some room to breathe so the compressor gets fresh air, and clean the condenser often. Extra shelves are Atosa part W0402387 (left and right sections) and W0402388 (middle section), and each comes with 4 shelf clips.
Atosa MBF8504GR FAQ
What size is the Atosa MBF8504GR?
The MBF8504GR is 81-9/10" wide, 31-7/10" deep and 83-1/10" tall. It weighs 551 lb (628 lb shipping weight).
How much does the MBF8504GR hold?
It holds 68 cu. ft. and comes with 9 pre-installed shelves, 3 per section.
What temperature does the MBF8504GR hold?
It holds -8°F to 0°F with a digital temperature control.
What power does the MBF8504GR need?
It runs on 115/208-230V / 60Hz / 1-phase and draws 6.2 amps. It has a NEMA L14-20P twist-lock plug, so you need a matching L14-20R outlet. Have an electrician check your outlet before it arrives.
Can I add more shelves to the MBF8504GR?
Yes. Order Atosa shelf W0402387 (left and right sections) and W0402388 (middle section). Each extra shelf comes with 4 shelf clips.
How do I keep the MBF8504GR running well?
Leave the unit some room to breathe so the compressor gets fresh air, and clean the condenser often. Those are the two tips on the Atosa spec sheet.
What warranty comes with the MBF8504GR?
3 years parts and labor and 5 years on the compressor.
Spec Sheet
Download the Atosa MBF8504GR spec sheet (PDF, Rev. 07/26)
OEM Parts We Stock for the MBF8504GR
The Restaurant Warehouse stocks genuine Atosa replacement parts for the MBF8504GR freezer, including the W0302317 temperature sensor/probe, the W0302316 probe, the W0310077 heater, the W0305134 power cord, and the W0304508 lamp socket with 2 male spade connectors. Explore the full Atosa parts hub or view the operating instructions for service procedures.
MBF8504GR Parts & Service
The MBF8504GR parts page lists genuine OEM Atosa replacement parts compatible with this unit. Additional service components are available in our Atosa parts collection, and the parts department guide covers ordering and warranty details.
