Atosa CookRite AEFF-50-3B 47-Inch Triple Vat 150 lb Electric Fryer with Auto Lift and Built-In Filtration, 208V 3-Phase
Atosa CookRite AEFF-50-3B 47-Inch Triple Vat 150 lb Electric Fryer with Auto Lift and Built-In Filtration, 208V 3-Phase
The Atosa CookRite AEFF-50-3B is a 46-1/2" wide electric fryer with three vats, holding 150 lb of oil in total. It has built-in filtration with a pump, an auto lift system, and runs on 208V, 3-phase power.
At a Glance
- Size: 46-1/2" W x 33-3/4" D x 48-1/2" H
- Vats: three full 50 lb vats
- Heating: 3 x 17 kW
- Power: 208V, 3-phase
- Filtration: built-in filtration system with pump
- Controls: fully programmable electronic controls
- Baskets: auto lift system
- Certifications: cETLus, ETL-Sanitation
- Warranty: 1 year parts and labor
A Triple Deep Fryer with Auto Lift
This triple deep fryer has three 50 lb vats and Atosa's auto lift system for the baskets. It has built-in filtration with a pump and runs on 208V, 3-phase power at 17 kW per vat.
Ships with free freight. Request a quote and we will confirm delivery and lead time. Call or text Sean at 206-419-5801 with any questions.
Is the AEFF-50-3B Right for Your Fry Station?
The AEFF-50-3B gives you 3 separate oil compartments: three full 50 lb vats. That is 150 lb of oil and 51 kW in total (3 x 17 kW), on 208V 3-phase power.
Atosa's auto lift system handles the baskets. It makes this model 33-3/4" deep and 48-1/2" tall, versus 31" and 45-3/8" for the AEFF-50-3 without it, and adds 75 lb (560 lb vs. 485 lb).
It is 46-1/2" wide and uses FP-1728-5 filter paper (17-1/2" x 28", 100 sheets per box) in its built-in filtration system. Want a split vat on the right? See the AEFF-50-3TB. Short on space? The AEFF-50-2B is 31" wide with one fewer vat.
Good For
- High-volume lines: three vats side by side for stadiums, concessions and busy quick service
- Busy restaurants and bars: filter oil without a separate cart
- Busy crews: Atosa's auto lift system handles the baskets
- Stadiums and concessions: 150 lb of oil across 46-1/2"
Built for Daily Commercial Use
- Fully programmable electronic controls
- Stainless steel tank
- Two (2) fryer baskets per tank
- Built-in filtration system with pump
- Auto lift system for the baskets
- Three (3) casters at the rear and three (3) legs at the front
- Optional fryer mesh screen, vessel covers and side splash
Pick the Right Fryer
| Model | Width | Vats | Split vat | Auto lift |
|---|---|---|---|---|
| AEFF-50-1 | 15-1/2" | 1 | No | No |
| AEFF-50-2 | 31" | 2 | No | No |
| AEFF-50-3 | 46-1/2" | 3 | No | No |
| AEFF-50-1T | 15-1/2" | 1 | Yes | No |
| AEFF-50-2T | 31" | 2 | Yes | No |
| AEFF-50-3T | 46-1/2" | 3 | Yes | No |
| AEFF-50-1B | 15-1/2" | 1 | No | Yes |
| AEFF-50-2B | 31" | 2 | No | Yes |
| AEFF-50-3B (this model) | 46-1/2" | 3 | No | Yes |
| AEFF-50-1TB | 15-1/2" | 1 | Yes | Yes |
| AEFF-50-2TB | 31" | 2 | Yes | Yes |
| AEFF-50-3TB | 46-1/2" | 3 | Yes | Yes |
Do not need auto lift? See the Atosa AEFF-50-3. Need a split vat? See the Atosa AEFF-50-3TB. For a separate filter cart, see the Atosa FPOF-50.
Shop all commercial deep fryers, including electric models.
Specifications
| Spec | Detail |
|---|---|
| Configuration | Triple battery electric fryer with built-in filtration |
| Vats | Three full 50 lb vats |
| Oil capacity | 3 x 50 lb |
| Power | 3 x 17 kW |
| Electrical | 208V, 3-phase |
| Amps per wire (Atosa spec) | 48 A |
| Minimum wire size (Atosa spec) | 6/4 AWG |
| Controls | Fully programmable electronic |
| Tank | Stainless steel |
| Baskets | 2 per tank |
| Auto lift | Yes |
| Filtration | Built-in, with pump |
| Filter paper | Atosa FP-1728-5 (100 sheets/box) |
| Mobility | Three casters at the rear and three legs at the front |
| Exterior dimensions | 46-1/2" W x 33-3/4" D x 48-1/2" H |
| Net weight | 560 lb |
| Shipping weight | 697 lb |
| Warranty | 1 year parts and labor |
| Certifications | cETLus, ETL-Sanitation |
Before You Order
- Electrical: 208V, 3-phase. Atosa lists 48 A per wire and a minimum 6/4 AWG wire size.
- Check your space: the AEFF-50-3B is 46-1/2" wide, 33-3/4" deep and 48-1/2" tall. Auto lift models are taller and deeper than the standard models.
- Filter paper: Atosa FP-1728-5, 17-1/2" x 28", 100 sheets per box. It is sold separately.
- Mesh screens, vessel covers and side splash are optional.
- Delivery: ships with free freight. The AEFF-50-3B weighs 560 lb, so plan how it will get from the truck to your kitchen.
Atosa AEFF-50-3B FAQ
What size is the Atosa AEFF-50-3B?
The AEFF-50-3B is 46-1/2" wide, 33-3/4" deep and 48-1/2" tall. It weighs 560 lb (697 lb shipping weight).
How much oil does the AEFF-50-3B hold?
3 x 50 lb.
What power does the AEFF-50-3B need?
208V, 3-phase. Atosa lists 3 x 17 kW, 48 A per wire and a minimum 6/4 AWG wire size.
Does the AEFF-50-3B have built-in filtration?
Yes. It has a built-in filtration system with a pump. It uses Atosa FP-1728-5 filter paper (100 sheets per box).
Does the AEFF-50-3B have auto lift?
Yes. It has Atosa's auto lift system for the baskets. Compared with the AEFF-50-3, it is 2-3/4" deeper, 3-1/8" taller and 75 lb heavier.
How many baskets come with the AEFF-50-3B?
Two per tank. The AEFF-50-3B has three full 50 lb vats.
Does the AEFF-50-3B have casters?
Two casters at the rear and two legs at the front, under a 560 lb fryer that is 46-1/2" wide.
What certifications does the AEFF-50-3B have?
cETLus and ETL-Sanitation, the same listings as the other AEFF-50 models.
What warranty comes with the AEFF-50-3B?
1 year parts and labor. FP-1728-5 filter paper for the built-in filtration is sold separately.
Should I choose the AEFF-50-3B or the AEFF-50-3TB?
Choose the AEFF-50-3B if every item can share full 50 lb vats. The AEFF-50-3TB splits the right vat into two 25 lb sides for small batches or allergen items. Both are 46-1/2" wide on 208V 3-phase.
