Atosa CookRite AEFF-50-1TB 16-Inch Split Vat Electric Fryer, (2) 25 lb, Auto Lift, Built-In Filtration, 208V 3-Phase
Atosa CookRite AEFF-50-1TB 16-Inch Split Vat Electric Fryer, (2) 25 lb, Auto Lift, Built-In Filtration, 208V 3-Phase
The Atosa CookRite AEFF-50-1TB is a 15-1/2" wide electric fryer with one vat including a split vat, holding 50 lb of oil in total. It has built-in filtration with a pump, an auto lift system, and runs on 208V, 3-phase power.
At a Glance
- Size: 15-1/2" W x 33-3/4" D x 48-1/2" H
- Vats: one split vat with two 25 lb sides
- Heating: 2 x 8.5 kW
- Power: 208V, 3-phase
- Filtration: built-in filtration system with pump
- Controls: fully programmable electronic controls
- Baskets: auto lift system
- Certifications: cETLus, ETL-Sanitation
- Warranty: 1 year parts and labor
A Split Pot Fryer with Auto Lift
This split pot fryer divides one vat into two 25 lb sides and adds Atosa's auto lift system for the baskets. It has built-in filtration with a pump and runs on 208V, 3-phase power.
Ships with free freight. Request a quote and we will confirm delivery and lead time. Call or text Sean at 206-419-5801 with any questions.
Is the AEFF-50-1TB Right for Your Fry Station?
The AEFF-50-1TB gives you 2 separate oil compartments: one split vat with two 25 lb sides. That is 50 lb of oil and 17 kW in total (2 x 8.5 kW), on 208V 3-phase power. Each 25 lb side runs on its own 8.5 kW, so a gluten-free or seafood item never shares oil with the rest of the menu.
Atosa's auto lift system handles the baskets. It makes this model 33-3/4" deep and 48-1/2" tall, versus 31" and 45-3/8" for the AEFF-50-1T without it, and adds 8 lb (251 lb vs. 243 lb).
It is 15-1/2" wide and uses FP-1324-5 filter paper (13-1/2" x 24", 100 sheets per box) in its built-in filtration system. Want a full 50 lb vat instead? See the AEFF-50-1B. Need more capacity? The AEFF-50-2TB adds another 50 lb vat at 31" wide.
Good For
- Small batches: two 25 lb sides in a 15-1/2" footprint
- Seafood or gluten-free menus: a separate 25 lb side with its own 8.5 kW
- Busy crews: Atosa's auto lift system handles the baskets
- Kitchens with a 16" opening: 15-1/2" wide
Built for Daily Commercial Use
- Fully programmable electronic controls
- Stainless steel tank
- Two (2) fryer baskets per tank
- Built-in filtration system with pump
- Auto lift system for the baskets
- Two (2) casters at the rear and two (2) legs at the front
- Optional fryer mesh screen, vessel covers and side splash
Pick the Right Fryer
| Model | Width | Vats | Split vat | Auto lift |
|---|---|---|---|---|
| AEFF-50-1 | 15-1/2" | 1 | No | No |
| AEFF-50-2 | 31" | 2 | No | No |
| AEFF-50-3 | 46-1/2" | 3 | No | No |
| AEFF-50-1T | 15-1/2" | 1 | Yes | No |
| AEFF-50-2T | 31" | 2 | Yes | No |
| AEFF-50-3T | 46-1/2" | 3 | Yes | No |
| AEFF-50-1B | 15-1/2" | 1 | No | Yes |
| AEFF-50-2B | 31" | 2 | No | Yes |
| AEFF-50-3B | 46-1/2" | 3 | No | Yes |
| AEFF-50-1TB (this model) | 15-1/2" | 1 | Yes | Yes |
| AEFF-50-2TB | 31" | 2 | Yes | Yes |
| AEFF-50-3TB | 46-1/2" | 3 | Yes | Yes |
Do not need auto lift? See the Atosa AEFF-50-1T. For all full vats, see the Atosa AEFF-50-1B. For a separate filter cart, see the Atosa FPOF-50.
Shop all commercial deep fryers, including electric models.
Specifications
| Spec | Detail |
|---|---|
| Configuration | Single battery electric fryer with built-in filtration |
| Vats | One split vat with two 25 lb sides |
| Oil capacity | 2 x 25 lb (split vat) |
| Power | 2 x 8.5 kW |
| Electrical | 208V, 3-phase |
| Amps per wire (Atosa spec) | 48 A |
| Minimum wire size (Atosa spec) | 6/4 AWG |
| Controls | Fully programmable electronic |
| Tank | Stainless steel |
| Baskets | 2 per tank |
| Auto lift | Yes |
| Filtration | Built-in, with pump |
| Filter paper | Atosa FP-1324-5 (100 sheets/box) |
| Mobility | Two casters at the rear and two legs at the front |
| Exterior dimensions | 15-1/2" W x 33-3/4" D x 48-1/2" H |
| Net weight | 251 lb |
| Shipping weight | 326 lb |
| Warranty | 1 year parts and labor |
| Certifications | cETLus, ETL-Sanitation |
Before You Order
- Electrical: 208V, 3-phase. Atosa lists 48 A per wire and a minimum 6/4 AWG wire size.
- Check your space: the AEFF-50-1TB is 15-1/2" wide, 33-3/4" deep and 48-1/2" tall. Auto lift models are taller and deeper than the standard models.
- Filter paper: Atosa FP-1324-5, 13-1/2" x 24", 100 sheets per box. It is sold separately.
- Mesh screens, vessel covers and side splash are optional.
- Delivery: ships with free freight. The AEFF-50-1TB weighs 251 lb, so plan how it will get from the truck to your kitchen.
Atosa AEFF-50-1TB FAQ
What size is the Atosa AEFF-50-1TB?
The AEFF-50-1TB is 15-1/2" wide, 33-3/4" deep and 48-1/2" tall. It weighs 251 lb (326 lb shipping weight).
How much oil does the AEFF-50-1TB hold?
2 x 25 lb (split vat). The split vat has two 25 lb sides, so you can fry two foods apart.
What power does the AEFF-50-1TB need?
208V, 3-phase. Atosa lists 2 x 8.5 kW, 48 A per wire and a minimum 6/4 AWG wire size.
Does the AEFF-50-1TB have built-in filtration?
Yes. It has a built-in filtration system with a pump. It uses Atosa FP-1324-5 filter paper (100 sheets per box).
Does the AEFF-50-1TB have auto lift?
Yes. It has Atosa's auto lift system for the baskets. Compared with the AEFF-50-1T, it is 2-3/4" deeper, 3-1/8" taller and 8 lb heavier.
How many baskets come with the AEFF-50-1TB?
Two per tank. The AEFF-50-1TB has one split vat with two 25 lb sides.
Does the AEFF-50-1TB have casters?
Two casters at the rear and two legs at the front, under a 251 lb fryer that is 15-1/2" wide.
What certifications does the AEFF-50-1TB have?
cETLus and ETL-Sanitation, the same listings as the other AEFF-50 models.
What warranty comes with the AEFF-50-1TB?
1 year parts and labor. FP-1324-5 filter paper for the built-in filtration is sold separately.
Should I choose the AEFF-50-1TB or the AEFF-50-1B?
The AEFF-50-1TB pairs the auto lift with a vat split into two 25 lb sides, each with its own 8.5 kW. The AEFF-50-1B keeps the auto lift but uses one full 50 lb vat. Pick the AEFF-50-1TB if any item needs its own oil.
