Atosa MBF8505GRL 27-Inch One Door Commercial Reach-In Refrigerator, Left Hinge, Bottom Mount, 19.1 cu. ft.

Atosa MBF8505GRL 27-Inch One Door Commercial Reach-In Refrigerator, Left Hinge, Bottom Mount, 19.1 cu. ft.

The Atosa MBF8505GRL is an 27-inch left-hinge single-door bottom-mount reach-in refrigerator, intended for kitchen layouts requiring a left-hinged door instead of the standard MBF8505GR configuration. It holds 19.1 cu. ft. at 35°F to 38°F and plugs into a standard 115V outlet.

It is the left-hinge version of our MBF8505GR, with the door swinging open to the left. Pick it when there is a wall on its left side, so the open door rests against the wall.

At a Glance

• Size: 27" W x 31.7" D x 83.1" H
• Storage: 19.1 cu. ft., 3 shelves
• Door: locking solid door (left-hinged), self-closing with stay-open feature
• Temperature: 35°F to 38°F
• Power: 115V, 2.1 amps, standard plug (NEMA 5-15P)
• ENERGY STAR® certified
• Warranty: 3 years parts and labor, 5 years compressor

Most units ship within one business day from our warehouse with free freight to the lower 48.

A Left Hinge Bottom Mount Refrigerator

This left hinge bottom mount refrigerator opens to the left, so the open door rests against a wall on its left side instead of blocking your walkway. Inside, it is the same refrigerator as the MBF8505GR, with 19.1 cu. ft. and 3 shelves.

Best Uses for the MBF8505GRL

• Left-hinge kitchen layouts: A 27-inch single-door cabinet with its door hinged on the left
• Compact prep areas: 19.1 cu. ft. and three shelves where a two-door refrigerator will not fit
• Wall-adjacent installation planning: Choose the hinge direction that best accommodates nearby work areas and door clearance

Where the Left-Hinge MBF8505GRL Fits Best

• Bottom-mount with a left wall: the compressor sits below the cabinet, so the shelves start higher, and the door folds back toward the left wall
• Bakeries and prep rooms with the counter on the right: the upper shelves of the 83.1" tall cabinet are easy to reach from the right, beside the counter
• Next to the MBF8505GR: at 27" wide each, the pair fits 54" of wall with the doors opening away from each other

Built for Daily Commercial Use

• Stainless steel inside and out
• Bottom mount compressor with R290, a natural refrigerant
• Electronic temperature controller
• Down duct airflow spreads cold air evenly
• Self-closing door with a stay-open feature, opens to 105°
• Door lock standard, recessed handle, magnetic gasket
• LED interior lights
• Pre-installed 4" casters

Pick the Right Model

Need the same cabinet for frozen food? See the matching Atosa MBF8501GRL left-hinge one door freezer.

Need a different size? Shop all bottom mount refrigerators, or compare reach-in refrigerators.

Specifications

Before You Order

• Plan for a standard 115V outlet with a NEMA 5-15 receptacle.
• Check your doorways: the unit is 31.7" deep and 83.1" tall.
• Pick your hinge: the MBF8505GRL door is hinged on the left.
• Leave the unit some room to breathe and clean the condenser often, as Atosa advises.
• Extra shelves are Atosa part W0402393, and each comes with 4 shelf clips.

Atosa MBF8505GRL FAQ

What is the difference between MBF8505GRL and MBF8505GR?

They are the same 27" cabinet with 19.1 cu. ft. and the same solid door. The only difference is the hinge side. Stand where the unit will go and face the front: if the wall or nearest equipment is on your left, the MBF8505GRL opens toward it and keeps the right side clear. If it is on your right, choose the MBF8505GR.

What size is the Atosa MBF8505GRL?

The MBF8505GRL is 27" wide, 31.7" deep and 83.1" tall. It weighs 249 lb (282 lb shipping weight).

How much does the MBF8505GRL hold?

It holds 19.1 cu. ft. and comes with 3 shelves.

What temperature does the MBF8505GRL hold?

It holds 35°F to 38°F with an electronic temperature controller.

Which way does the MBF8505GRL door open?

The door is hinged on the left. The MBF8505GR is the same refrigerator hinged on the right.

Is the MBF8505GRL ENERGY STAR® certified?

Yes. It is ENERGY STAR® certified.

What power does the MBF8505GRL need?

It runs on 115V and draws 2.1 amps. It has a standard NEMA 5-15P plug, so it plugs into a regular 115V outlet.

Can I add more shelves to the MBF8505GRL?

Yes. Order Atosa shelf W0402393. Each extra shelf comes with 4 shelf clips.

How often should I clean the MBF8505GRL condenser?

Atosa says to clean the condenser frequently. Pull the unit out on its casters, vacuum the condenser coil, and brush off any flour, dust or grease. A clean condenser helps the refrigerator hold temperature.

What warranty comes with the MBF8505GRL?

3 years parts and labor and 5 years on the compressor.

Spec Sheet

Download the Atosa MBF8505GRL spec sheet (PDF, Rev. 10/26)
