Atosa MBF8506GR 40-Inch Two Door Commercial Reach-In Refrigerator, Bottom Mount, 28.5 cu. ft.

Atosa MBF8506GR 40-Inch Two Door Commercial Reach-In Refrigerator, Bottom Mount, 28.5 cu. ft.

The Atosa MBF8506GR is an 40-inch narrow two-door bottom-mount reach-in refrigerator with six shelves, designed to fit tighter spaces than the full-width 54-inch two-door model. It holds 28.5 cu. ft. at 35°F to 38°F and plugs into a standard 115V outlet.

Two doors open to 28.5 cu. ft. and 6 shelves in a 39-1/2" wide cabinet. It is about 15" narrower than the 54" MBF8507GR, so it fits where a full size two door will not. Shopping for a food truck? See the low height MBF8519GR.

At a Glance

• Size: 39-1/2" W x 31.7" D x 83.1" H
• Storage: 28.5 cu. ft., 6 shelves, 3 per section
• Doors: locking solid doors, self-closing with stay-open feature
• Temperature: 35°F to 38°F
• Power: 115V, 3.2 amps, standard plug (NEMA 5-15P)
• Warranty: 3 years parts and labor, 5 years compressor

Most units ship within one business day from our warehouse with free freight to the lower 48.

A Narrow Two Door Refrigerator

At 39-1/2" wide, this 40 inch commercial refrigerator is about 15" narrower than our 54" two door models. It gives you 28.5 cu. ft. and 6 shelves in a small kitchen or a narrow back room. The compressor is at the bottom, which keeps the top of the cabinet clear.

Best Uses for the MBF8506GR

• Narrow two-section kitchen layouts: Two-door access in a 39-1/2-inch-wide cabinet
• Restaurant prep operations: 28.5 cu. ft. across six shelves for organizing ingredients
• Space-constrained production kitchens: A smaller-width alternative to the 54-inch MBF8507GR

Built for Daily Commercial Use

• Stainless steel inside and out
• Bottom mount compressor with R290, a natural refrigerant
• Electronic temperature controller
• Down duct airflow spreads cold air evenly
• Self-closing doors with a stay-open feature, opens to 105°
• Door locks standard, recessed handles, magnetic gaskets
• LED interior lights
• Pre-installed 4" casters

Pick the Right Model

Need the same cabinet for frozen food? See the matching Atosa MBF8502GR two door freezer.

Need a different size? Shop all bottom mount refrigerators, or compare reach-in refrigerators.

Specifications

Before You Order

• Plan for a standard 115V outlet with a NEMA 5-15 receptacle.
• Check your doorways: the unit is 31.7" deep and 83.1" tall.
• Leave the unit some room to breathe and clean the condenser often, as Atosa advises.

Atosa MBF8506GR FAQ

Why choose the MBF8506GR instead of the MBF8507GR?

The MBF8506GR is approximately 40 inches wide with 28.5 cu. ft., while the MBF8507GR is approximately 54 inches wide with 43.8 cu. ft. Both have two doors and six shelves; choose based on required capacity and available width.

What size is the Atosa MBF8506GR?

The MBF8506GR is 39-1/2" wide, 31.7" deep and 83.1" tall. It weighs 317 lb (365 lb shipping weight).

How much does the MBF8506GR hold?

It holds 28.5 cu. ft. and comes with 6 shelves, 3 per section.

What temperature does the MBF8506GR hold?

It holds 35°F to 38°F with an electronic temperature controller.

What power does the MBF8506GR need?

It runs on 115V and draws 3.2 amps. It has a standard NEMA 5-15P plug, so it plugs into a regular 115V outlet.

How often should I clean the MBF8506GR condenser?

Atosa says to clean the condenser frequently. Pull the unit out on its casters, vacuum the condenser coil, and brush off any flour, dust or grease. A clean condenser helps the refrigerator hold temperature.

What warranty comes with the MBF8506GR?

3 years parts and labor and 5 years on the compressor.

Spec Sheet

Download the Atosa MBF8506GR spec sheet (PDF, Rev. 10/26)
