Atosa CookRite EHS-OW-3 Electric 3 Well Steam Table, 120V, 1,425W
Atosa CookRite EHS-OW-3 Electric 3 Well Steam Table, 120V, 1,425W
The Atosa EHS-OW-3 is a CookRite electric steam table with 3 open wells and 1,425 W on 120V. Each well has its own control, and it comes with a poly cutting board and water pans.
At a Glance
- Size: 44-1/8" W x 29-1/2" D x 33-1/2" H
- Wells: 3 open wells, 12" x 20" openings, 8" deep, each holds a full-size food pan, 6" deep
- Heat: 475 W per well, 1,425 W total, dry heat
- Controls: one infinite switch and indicator light per well
- Electrical (as Atosa lists): 120V, 60 Hz, NEMA 5-15P plug
- Cutting board: 7" wide x 1/2" thick poly
- Certifications: cETLus, ETL-Sanitation
- Warranty: 1 year parts and labor
Most units ship within one business day from our warehouse with free freight to the lower 48.
A 3 Well Steam Table, 44-1/8" Wide
This 3 well steam table is 44-1/8" wide and holds three full-size pans, 6" deep. Each well runs at 475 W on its own infinite switch.
The EHS-OW-3 is the largest EHS-OW that still runs on a standard NEMA 5-15P plug. It draws 1,425 W across 3 wells, so you get a third pan without upgrading to a 20 A receptacle.
It is 44-1/8" wide and weighs 108 lb. Three full-size pans, 6" deep, cover a common lunch setup: a protein, a starch and a vegetable.
For 4 pans, the EHS-OW-4 needs a NEMA 5-20P receptacle. If space is tight, the EHS-OW-2 is 30" wide. The matching sneeze guard is the MROS-3ST.
Good For
- Lunch counters: protein, starch and vegetable in one table
- Mexican and Asian restaurants: rice, beans or sauces next to proteins
- Schools and break rooms: a short serving line on 120V
- Delis: soups and hot sides at the counter
Built for Daily Commercial Use
- Fully insulated open wells: all four sides and the bottom are insulated with fiberglass
- 8" deep open wells that heat dry
- Individual infinite switch controls each well
- 475 W heating element per well
- Indicator light on each well shows power on and element heating
- Mechanical guards on all switches
- Stainless steel die-stamped 12" x 20" openings with a rising lip that helps keep the well clean and makes pans easy to load and unload
- Poly cutting board, 7" wide x 1/2" thick, on an 18 gauge stainless steel support shelf and brackets
- 18 gauge stainless steel top, body and undershelf
- Stainless steel tubular legs with adjustable stainless steel feet
- Water pans included
Add-Ons
- Sneeze guard: Atosa MROS-3ST overshelf and sneeze guard, 44-3/10" x 12-1/5" x 16-1/10", rated for 70 lb
- Casters: set of 4, item E140201235022, two with brakes and two without
Pick the Right Size
| Model | Wells | Width | Watts | Volts | Plug |
|---|---|---|---|---|---|
| EHS-OW-2 | 2 | 30" | 950 | 120V | NEMA 5-15P |
| EHS-OW-3 (this model) | 3 | 44-1/8" | 1,425 | 120V | NEMA 5-15P |
| EHS-OW-4 | 4 | 58-1/4" | 1,900 | 120V | NEMA 5-20P |
| EHS-OW-5 | 5 | 72-1/4" | 3,750 | 240V | NEMA 6-20P |
Shop all food holding equipment and commercial food warmers.
Specifications
| Spec | Detail |
|---|---|
| Type | Electric steam table, open well, dry heat |
| Wells | 3 |
| Pan type | (3) full-size food pan, 6" depth |
| Well openings | 12" x 20", die-stamped stainless steel |
| Well depth | 8" |
| Watts per well | 475 |
| Rated power (W) | 1,425 |
| Voltage / frequency (as Atosa lists) | 120V / 60 Hz |
| Plug (as Atosa lists) | NEMA 5-15P |
| Controls | Infinite switch and indicator light per well |
| Cutting board | 7" wide x 1/2" thick poly, 18 gauge stainless support |
| Construction | 18 gauge stainless steel top, body and undershelf |
| Legs | Stainless steel tubular, adjustable stainless steel feet |
| Included | Water pans |
| Optional casters | Set of 4, item E140201235022 (two with brakes, two without) |
| Optional sneeze guard | MROS-3ST, 44-3/10" x 12-1/5" x 16-1/10", 70 lb weight capacity |
| Exterior dimensions | 44-1/8" W x 29-1/2" D x 33-1/2" H |
| Net weight | 108 lb |
| Gross weight | 121 lb |
| Warranty | 1 year parts and labor |
| Certifications | cETLus, ETL-Sanitation |
Before You Order
- Electrical: Atosa lists 120V, 60 Hz, 1,425 W with a NEMA 5-15P plug.
- Check your space: the EHS-OW-3 is 44-1/8" wide, 29-1/2" deep and 33-1/2" tall. It weighs 108 lb.
- Pans: each well takes a full-size food pan, 6" deep.
Atosa EHS-OW-3 FAQ
What size is the Atosa EHS-OW-3?
44-1/8" W x 29-1/2" D x 33-1/2" H. It weighs 108 lb, or 121 lb shipped.
How many pans does the EHS-OW-3 hold?
3 full-size food pans, 6" deep. Each 12" x 20" well holds one.
How many watts is the EHS-OW-3?
1,425 W in total. Each of the 3 wells has a 475 W element.
What power does the EHS-OW-3 need?
120V, 60 Hz, with a NEMA 5-15P plug, per Atosa. It is the largest EHS-OW on a 15 A plug.
Can I control each well separately on the EHS-OW-3?
Yes. Each of the 3 wells has an infinite switch and a light that shows power and heating, so the middle well can run at a different setting.
Is the EHS-OW-3 a wet or dry steam table?
It is an open well, dry heat design, per Atosa. Water pans are included with the EHS-OW-3.
Does the EHS-OW-3 have a cutting board?
Yes, a poly board 7" wide and 1/2" thick that runs along the 44-1/8" table on a stainless steel support shelf.
What sneeze guard fits the EHS-OW-3?
The MROS-3ST, which is 44-3/10" x 12-1/5" x 16-1/10" with a 70 lb shelf rating from Atosa.
Can I add casters to the EHS-OW-3?
Yes. Order the Atosa caster set, item E140201235022: 4 casters, 2 with brakes and 2 without.
Did the EHS-OW-3 replace the CSTEA-3C?
Yes. The EHS-OW-3 is the current Atosa model number for the 3 well electric steam table that was sold as the CSTEA-3C.
What certifications does the EHS-OW-3 have?
The EHS-OW-3 is cETLus and ETL-Sanitation listed.
What warranty comes with the EHS-OW-3?
1 year parts and labor from Atosa on the EHS-OW-3.
Will the EHS-OW-3 plug into a regular outlet?
Yes. Atosa lists a NEMA 5-15P plug at 120V and 1,425 W, so it fits a standard 15 A, 120V receptacle. The EHS-OW-4 needs a 20 A receptacle.
Spec Sheet
Download the Atosa EHS-OW-3 spec sheet (PDF, Rev. 09/26)
CSTEA-3 Parts & Service
For OEM replacement parts for the CSTEA-3, see the CSTEA-3 parts list, with part numbers and quantities from Atosa's exploded-view diagram. Parts lists for every model are on the Atosa parts lists index.
