Atosa MCF8732GR 40-Inch Two Glass Door Black Merchandiser Freezer, 28.5 cu. ft.
Atosa MCF8732GR 40-Inch Two Glass Door Black Merchandiser Freezer, 28.5 cu. ft.
The Atosa MCF8732GR is a two-door glass merchandiser freezer with a bottom mount compressor. It holds 28.5 cu. ft. at -8°F to 0°F and plugs into a standard 115V outlet.
At 39-1/2" wide it sits between the 27" one door and the 54" two door models. Two glass doors and eight shelves give you a full display without a full 54" footprint.
Need a different size? Shop all glass door freezers or compare commercial freezers.
Most units ship within one business day from our warehouse with free freight to the lower 48.
A Retail Freezer for Grocery and Convenience Stores
The Atosa MCF8732GR is a 40 inch glass door merchandiser freezer with two glass doors, eight shelves and 28.5 cu. ft. of frozen display space. At 39-1/2 inches wide, this narrow two door display freezer fits retail spaces that need more capacity than a single-door case but cannot accommodate a 54-inch model. Its black cabinet makes it a practical upright retail freezer for packaged frozen food and ice cream.
Where the MCF8732GR Fits Best
- Convenience stores: ice cream, novelties and frozen meals
- Grocery and markets: packaged frozen foods customers can see
- Cafés and delis: grab-and-go frozen items
- Ice cream and dessert shops: pints, bars and cakes on display
Why a Glass Door Freezer Sells More
Shoppers buy with their eyes first. With a glass door, they see what you have without opening it. That means faster choices, more impulse buys and fewer door openings.
- 28.5 cu. ft. in a 39-1/2" wide cabinet
- Holds -8°F to 0°F for ice cream, novelties and frozen meals
- Self-closing double-pane glass doors with locks
- 8 shelves and LED interior lighting, plus a lighted header panel
- 3-year parts and labor and 5-year compressor warranty
Cooling and Controls
A 3/4 HP compressor runs on R290, a natural refrigerant. An electronic temperature controller holds -8°F to 0°F, and a down duct channel spreads cold air evenly. The lighted header panel and LED interior lights keep the display bright.
Built for Daily Commercial Use
The exterior is black steel and the interior is stainless steel. The doors are double-pane glass, close on their own and have a stay-open feature, which makes restocking easier. Each door locks, the handles are recessed, and magnetic gaskets seal the doors. It rolls on pre-installed 2" casters.
Pick the Right Model
| Model | Glass doors | Width | Capacity | Shelves |
|---|---|---|---|---|
| MCF8720GR | 1 | 27" | 19.4 cu. ft. | 4 |
| MCF8720GRL | 1 (left hinge) | 27" | 19.4 cu. ft. | 4 |
| MCF8732GR (this model) | 2 | 39-1/2" | 28.5 cu. ft. | 8 |
| MCF8721ES | 2 | 54-2/5" | 43.8 cu. ft. | 8 |
| MCF8728GR | 3 | 81-9/10" | 68 cu. ft. | 12 |
Need the same cabinet for refrigerated food? See the matching Atosa MCF8733GR two door black glass refrigerator.
Specifications
| Spec | Detail |
|---|---|
| Configuration | Glass merchandiser freezer, two-section, bottom mount |
| Doors | (2) double-pane glass doors with locks, self-closing with stay-open feature |
| Capacity | 28.5 cu. ft. |
| Shelves | (8) shelves, 4 per section |
| Exterior dimensions | 39-1/2" W x 31-1/2" D x 81-1/5" H |
| Temperature range | -8°F to 0°F |
| Temperature control | Electronic |
| Refrigerant | R290 hydrocarbon |
| Compressor | 3/4 HP |
| Airflow | Down duct |
| Lighting | LED interior, lighted header panel |
| Construction | Black steel exterior, stainless steel interior |
| Casters | 2", pre-installed |
| Electrical | 115V / 60Hz / 1-phase, 8.6 amps |
| Plug | NEMA 5-15P |
| Net weight | 392 lb |
| Shipping weight | 443 lb |
| Extra shelf | W0402197 (each includes 4 shelf clips) |
| Warranty | 3-year parts and labor, 5-year compressor |
| Certifications | cETLus, ETL-Sanitation |
Installation and Care
Set the freezer on a level floor near a standard 115V outlet with a NEMA 5-15 receptacle. Leave the unit some room to breathe so the compressor gets fresh air, and clean the condenser often. Extra shelves are Atosa part W0402197, and each comes with 4 shelf clips.
Atosa MCF8732GR FAQ
When should I choose MCF8732GR over MCF8721ES?
The MCF8732GR is 40 inches wide with 28.5 cu. ft. The MCF8721ES is 54 inches wide with 43.8 cu. ft. Both are two-door black glass-door merchandiser freezers.
What size is the Atosa MCF8732GR?
The MCF8732GR is 39-1/2" wide, 31-1/2" deep and 81-1/5" tall. It weighs 392 lb (443 lb shipping weight).
How much does the MCF8732GR hold?
It holds 28.5 cu. ft. and comes with 8 shelves, 4 per section.
What temperature does the MCF8732GR hold?
It holds -8°F to 0°F with an electronic temperature controller.
Does the MCF8732GR have double-pane glass?
Yes. The doors use double-pane glass, and they close on their own.
What power does the MCF8732GR need?
It runs on 115V / 60Hz / 1-phase and draws 8.6 amps. It has a NEMA 5-15P plug, so it plugs into a standard 115V outlet.
Can I add more shelves to the MCF8732GR?
Yes. Order Atosa shelf W0402197. Each extra shelf comes with 4 shelf clips.
How often should I clean the MCF8732GR condenser?
Atosa says to clean the condenser frequently. Pull the unit out on its casters, vacuum the condenser coil, and brush off any flour, dust or grease. A clean condenser helps the freezer hold temperature.
What warranty comes with the MCF8732GR?
3 years parts and labor and 5 years on the compressor.
Spec Sheet
Download the Atosa MCF8732GR spec sheet (PDF, Rev. 07/26)
Replacement Parts & Service for the MCF8732GR
Every MCF8732GR eventually needs routine service parts. We stock the most commonly requested OEM components including the W0201835 compressor kit, the W0412483 glass door (right) for mcf8732gr, the W0412482 door, the 87320405 bottom panel, and the W041075403 top panel. See related parts in the Atosa parts collection or review the parts department guide for ordering details.
MCF8732GR Parts & Service
Service and maintenance for the MCF8732GR: see the MCF8732GR parts breakdown for OEM replacement components. Shop all Atosa parts or reference the Atosa parts manuals to confirm your model.
