Atosa MCF8701GRL 27-Inch Glass Door Merchandiser Freezer, Left Hinge, 19.1 cu. ft.
Atosa MCF8701GRL 27-Inch Glass Door Merchandiser Freezer, Left Hinge, 19.1 cu. ft.
The Atosa MCF8701GRL is a one door glass door merchandiser freezer with a bottom mount compressor. It holds 19.1 cu. ft. at -8°F to 0°F and plugs into a standard 115V outlet.
It is the left-hinge version of our MCF8701GR, with the door swinging open to the left. Pick it when there is a wall on its left side, so the open door rests against the wall and out of the way.
Need a different size? Shop all glass door freezers or compare commercial freezers.
Most units ship within one business day from our warehouse with free freight to the lower 48.
A Left Hinge Glass Door Freezer
The Atosa MCF8701GRL is a left hinge glass door merchandiser freezer with 19.1 cu. ft. of display storage and four shelves. Its glass door opens to the left, giving stores and cafés a single glass door display freezer for layouts that require that door swing. It has the same stainless-steel cabinet and capacity as the MCF8701GR, with the hinges on the opposite side.
Where the Left-Hinge MCF8701GRL Fits Best
- A left wall or corner: the door swings toward the wall, so the right side stays open for shoppers to reach in
- Aisles where traffic comes from the right: customers open it without stepping around the door
- A row of merchandisers: set it on the left end next to the MCF8701GR so the doors open away from each other
- Stores with left-hinge layouts: position the door swing to suit nearby walls, aisles and fixtures
Before you buy: This model has a left-hinged door. Check the swing, 27" cabinet width and delivery path. It uses a standard 115V outlet with a NEMA 5-15P plug. For the opposite hinge, see the MCF8701GR.
Why a Glass Door Freezer Sells More
Shoppers buy with their eyes first. With a glass door, they see what you have without opening it. That means faster choices, more impulse buys and less cold air lost.
- 19.1 cu. ft. in a 27" wide cabinet
- Holds -8°F to 0°F for ice cream, novelties and frozen meals
- Self-closing double-pane glass door with lock (left-hinged)
- 4 adjustable shelves and LED interior lighting
- 3-year parts and labor and 5-year compressor warranty
Cooling and Controls
A 1/2 HP Embraco compressor runs on R290, a natural refrigerant. A digital controller holds -8°F to 0°F, and automatic evaporation takes care of condensate water for you. Bright LED lights keep the display clean and inviting.
Built for Daily Commercial Use
The inside and outside are stainless steel, and the back is galvanized steel. The door is double-pane glass, closes on its own and stays open when you swing it all the way, which makes restocking easier. The door locks, the handle is recessed, and magnetic gaskets seal tight. It rolls on pre-installed 4" casters.
Pick the Right Size
Atosa makes this glass door freezer in three versions. All hold -8°F to 0°F:
| Model | Glass doors | Width | Capacity | Shelves |
|---|---|---|---|---|
| MCF8701GR | 1 | 27" | 19.1 cu. ft. | 4 |
| MCF8701GRL (this model) | 1 (left hinge) | 27" | 19.1 cu. ft. | 4 |
| MCF8703ES | 2 | 54-3/8" | 44.8 cu. ft. | 8 |
Need the same size cabinet for refrigerated food? See the matching Atosa MCF8705GRL left-hinge glass door refrigerator.
Specifications
| Spec | Detail |
|---|---|
| Configuration | Glass door merchandiser freezer, one-section, bottom mount |
| Doors | (1) self-closing hinged double-pane glass door with lock (left-hinged) |
| Capacity | 19.1 cu. ft. |
| Shelves | (4) adjustable shelves |
| Exterior dimensions | 27" W x 31-3/4" D x 83-1/8" H |
| Temperature range | -8°F to 0°F |
| Temperature control | Digital |
| Refrigerant | R290 hydrocarbon |
| Compressor | 1/2 HP, Embraco |
| Condensate | Automatic evaporation |
| Lighting | Interior LED |
| Construction | Stainless steel interior and exterior, galvanized steel back |
| Casters | 4", pre-installed |
| Electrical | 115V / 60Hz / 1-phase, 6.3 amps |
| Plug | NEMA 5-15P |
| Net weight | 309 lb |
| Shipping weight | 342 lb |
| Extra shelf | W0402394 (each includes 4 shelf clips) |
| Warranty | 3-year parts and labor, 5-year compressor |
| Certifications | cETLus, ETL-Sanitation |
Installation and Care
Set the freezer on a level floor near a standard 115V outlet with a NEMA 5-15 receptacle. Leave the unit some room to breathe so the compressor gets fresh air, and clean the condenser often. Extra shelves are Atosa part W0402394, and each comes with 4 shelf clips.
Atosa MCF8701GRL FAQ
What size is the Atosa MCF8701GRL?
The MCF8701GRL is 27" wide, 31-3/4" deep and 83-1/8" tall. It weighs 309 lb (342 lb shipping weight).
How much does the MCF8701GRL hold?
It holds 19.1 cu. ft. and comes with 4 pre-installed shelves.
What temperature does the MCF8701GRL hold?
It holds -8°F to 0°F with a digital temperature control.
Which way does the MCF8701GRL door open?
The door is hinged on the left, so it swings open to the left. If you need it to open the other way, the MCF8701GR is the same freezer with the standard hinge.
Is the glass on the MCF8701GRL insulated?
Yes. The door uses double-pane glass, and it closes on its own and locks.
What power does the MCF8701GRL need?
It runs on 115V / 60Hz / 1-phase and draws 6.3 amps. It has a NEMA 5-15P plug, so it plugs into a standard 115V outlet.
Can I add more shelves to the MCF8701GRL?
Yes. Order Atosa shelf W0402394. Each extra shelf comes with 4 shelf clips.
How do I keep the MCF8701GRL running well?
Leave the unit some room to breathe so the compressor gets fresh air, and clean the condenser often. Those are the two tips on the Atosa spec sheet.
What warranty comes with the MCF8701GRL?
3 years parts and labor and 5 years on the compressor.
Spec Sheet
Download the Atosa MCF8701GRL spec sheet (PDF, Rev. 07/26)
Parts Compatibility for the MCF8701GRL
When your MCF8701GRL needs service, order genuine OEM Atosa parts direct from The Restaurant Warehouse. Frequently ordered items include the W0205026 solenoid valve body. Visit the Atosa parts catalog or consult the Atosa parts manuals for a full component breakdown.
