Atosa MBF15FSGRL 18-Inch Slimline Commercial Reach-In Freezer, Left Hinge, 13 cu. ft.
Atosa MBF15FSGRL 18-Inch Slimline Commercial Reach-In Freezer, Left Hinge, 13 cu. ft.
The Atosa MBF15FSGRL is a one door commercial reach-in freezer with a top mount compressor. It holds 13 cu. ft. at -8°F to 0°F and plugs into a standard 115V outlet.
It is the left-hinge version of our MBF15FSGR, with the door swinging open to the left. Pick it when there is a wall on its left side, so the open door rests against the wall and out of your way. At only 17-7/10" wide it fits a narrow gap, and it is ENERGY STAR® certified.
Need a different size? Shop all commercial freezers or compare reach-in freezers.
Most units ship within one business day from our warehouse with free freight to the lower 48.
A Left Hinge Slim Freezer
The Atosa MBF15FSGRL is a left hinge slimline commercial freezer measuring just 17-7/10 inches wide. Its single door swings open to the left, while the cabinet provides 13 cu. ft. of frozen storage. This narrow reach in freezer offers the same capacity as the MBF15FSGR with the opposite door swing for tight kitchen layouts.
Where the Left-Hinge MBF15FSGRL Fits Best
- A left wall or corner: the door opens against the wall and stays out of your walkway
- Work area on the right: you reach in from the right side, right beside your prep table or line
- Side-by-side units: place it to the left of the MBF15FSGR so both doors swing open away from each other
- Narrow gaps: the end of a cook line or beside a prep table
Why Kitchens Choose the MBF15FSGRL
- 13 cu. ft. in a 17-7/10" wide cabinet
- Holds -8°F to 0°F for meat, seafood, fries, desserts and prepared foods
- Locking solid door (left-hinged)
- 3 adjustable shelves and LED interior lighting
- ENERGY STAR® certified
- 3-year parts and labor and 5-year compressor warranty
Cooling and Controls
A 1/2 HP compressor runs on R290, a natural refrigerant. A digital controller holds -8°F to 0°F, and down duct airflow spreads cold air evenly from top to bottom. Automatic evaporation takes care of condensate water for you. It is a self-contained, plug-in unit, so there is nothing to plumb.
Built for a Commercial Kitchen
The inside and outside are stainless steel, so it stands up to spills and daily cleaning. The back is galvanized steel. The door closes on its own and stays open when you swing it all the way, which makes loading easier. It opens to 105°. The door locks, the handle is recessed so it does not catch on carts, and magnetic gaskets seal tight. It rolls on pre-installed 4" casters, so you can pull it out to clean behind it.
Why Top Mount?
On this freezer the compressor sits on top of the cabinet, up and away from floor dust, grease and mop water. Prefer the compressor on the bottom? See our bottom mount freezers.
Slimline and One Door Top Mount Freezers
All of these are top mount reach-ins that hold -8°F to 0°F:
| Model | Doors | Width | Capacity | Note |
|---|---|---|---|---|
| MBF15FSGR | 1 | 17-7/10" | 13 cu. ft. | Standard hinge |
| MBF15FSGRL (this model) | 1 | 17-7/10" | 13 cu. ft. | Left hinge |
| MBF8001GR | 1 | 28-7/10" | 21.4 cu. ft. | Wider one door top mount |
Need the same size cabinet for refrigerated food? See the matching Atosa MBF15RSGRL left-hinge slimline refrigerator.
Specifications
| Spec | Detail |
|---|---|
| Configuration | Reach-in freezer, one-section, top mount |
| Doors | (1) locking solid door (left-hinged), self-closing with stay-open feature |
| Capacity | 13 cu. ft. |
| Shelves | (3) adjustable epoxy-coated shelves |
| Exterior dimensions | 17-7/10" W x 37" D x 81-3/10" H |
| Temperature range | -8°F to 0°F |
| Temperature control | Digital |
| Refrigerant | R290 hydrocarbon |
| Compressor | 1/2 HP |
| Condensate | Automatic evaporation |
| Lighting | Interior LED |
| Construction | Stainless steel interior and exterior, galvanized steel back |
| Casters | 4", pre-installed |
| Electrical | 115V / 60Hz / 1-phase, 6.3 amps |
| Plug | NEMA 5-15P |
| Net weight | 198 lb |
| Shipping weight | 277 lb |
| Wall bracket | Standard, required for use |
| Extra shelf | R060040000003 (includes 4 shelf clips) |
| Warranty | 3-year parts and labor, 5-year compressor |
| Certifications | cETLus, ETL-Sanitation, ENERGY STAR® |
Installation and Care
Set the freezer on a level floor near a standard 115V outlet with a NEMA 5-15 receptacle. Attach the included wall bracket. Atosa says it is required for use. Leave the unit some room to breathe so the compressor gets fresh air, and clean the condenser often. Extra shelves are Atosa part R060040000003, and each comes with 4 shelf clips.
Atosa MBF15FSGRL FAQ
What size is the Atosa MBF15FSGRL?
The MBF15FSGRL is 17-7/10" wide, 37" deep and 81-3/10" tall. It weighs 198 lb (277 lb shipping weight).
How much does the MBF15FSGRL hold?
It holds 13 cu. ft. and comes with 3 pre-installed shelves.
What temperature does the MBF15FSGRL hold?
It holds -8°F to 0°F with a digital temperature control.
Which way does the MBF15FSGRL door open?
The door is hinged on the left, so it swings open to the left. If you need it to open the other way, the MBF15FSGR is the same freezer with the standard hinge.
Does the MBF15FSGRL need to be attached to the wall?
Yes. A wall bracket comes standard, and Atosa says it is required for use. Plan to anchor it to the wall when you set it up.
Is the MBF15FSGRL ENERGY STAR® certified?
Yes. It is ENERGY STAR® certified.
What power does the MBF15FSGRL need?
It runs on 115V / 60Hz / 1-phase and draws 6.3 amps. It has a NEMA 5-15P plug, so it plugs into a standard 115V outlet.
Can I add more shelves to the MBF15FSGRL?
Yes. Order Atosa shelf R060040000003. Each extra shelf comes with 4 shelf clips.
How do I keep the MBF15FSGRL running well?
Leave the unit some room to breathe so the compressor gets fresh air, and clean the condenser often. Those are the two tips on the Atosa spec sheet.
What warranty comes with the MBF15FSGRL?
3 years parts and labor and 5 years on the compressor.
Spec Sheet
Download the Atosa MBF15FSGRL spec sheet (PDF, Rev. 07/26)
Service Components & OEM Parts
The Restaurant Warehouse stocks genuine Atosa replacement parts for the MBF15FSGRL and other Atosa freezer models. Visit the Atosa parts hub or view the Atosa parts manuals for component compatibility.
